S40R3201N
RM105.00 MYR
Skip to product information
S40R3201N
RM105.00 MYR
Surge Protective Device T2 + T3 / Class II+III
Applications in:
- Main Switchboard
- Sub Switchboard
| Product | Surge Protective Device |
| Brand | GENWISE |
| Manufacturer, Owner, Designer | GENWISE Aitech Sdn Bhd |
| Standard Compliance | IEC 61643-11 |
| Type Classification | Type2 & Type 3 / Class 2 & Class 3 |
| Tested Waveforms | 8/20us / 6kV & 3kA |
| Test Report & Approval | International Test Report |
| Max. Discharge Current (Imax) : |
L-N @ 40kA N-PE @ 70kA |
| Open Circuit Voltage (Uoc) : | 6kV / 3kA |
| Nominal Discharge Current (In) : |
L-N @20kA N-PE @20kA |
| Max. Continuous Operating Voltage (MCOV/Uc) : |
L-N @ 320V N-PE @ 255V |
| Voltage Protection Level (Up) : |
L-N @ <1.5kV (T2) / < 1.0kV (T3) N-PE @ <1.5kV (T2) / < 1.3kV (T3) |
